Product Details:
|
| Part Number: | NJG2313VH | Type: | Cylindrical Roller Bearing |
|---|---|---|---|
| Feature: | Full Complement | Size: | 65x140x48mm |
| Weight: | 3.52 Kgs | HS Code: | 8482500090 |
| Cage: | No Cage , Full Of Rollers | Dynamic Load(kN): | 303 |
| Tatic Load(kN): | 360 | Reference Speed(r/min): | 1900 |
| Limiting Speed(r/min): | 2400 | ||
| High Light: | FAG Cylinder Roller Bearing,Single Row Cylinder Roller Bearing,NJG2313VH |
||
Cylindrical roller bearings are of high load capacity and can operate at high speeds because they use rollers as their rolling elements. They can therefore be used in applications involving heavy radial and impact loading.
The rollers are cylindrical in shape and crowned at the end in order to reduce the stress concentrations. They are also suitable for applications that require high speed because the rollers are guided by ribs which are either on the outer or inner ring.
There are different types designated as N, NU, NJ, NUP, NF, NCF, NJG, NUH (for single-row bearings like the following drawing); NNU, and NN (for double-row bearings depending on the design or absence of side ribs).
Mainly used in machine tools, metallurgy, gearboxes, ports, printing machinery.
| PartNo. | d | D | T | PartNo. |
| NCF3004CV | 20 | 42 | 16 | NCF 3004 CV |
| NCF3005CV | 25 | 47 | 16 | NCF 3005 CV |
| NJG2305VH | 25 | 62 | 24 | NJG 2305 VH |
| NCF3006CV | 30 | 55 | 19 | NCF 3006 CV |
| NJG2306VH | 30 | 72 | 27 | NJG 2306 VH |
| NCF3007CV | 35 | 62 | 20 | NCF 3007 CV |
| NCF3008CV | 40 | 68 | 21 | NCF 3008 CV |
| NJG2308VH | 40 | 90 | 33 | NJG 2308 VH |
| NCF3009CV | 45 | 75 | 23 | NCF 3009 CV |
| NJG309VH | 45 | 100 | 25 | NJG 309 VH |
| NJG2309VH | 45 | 100 | 36 | NJG 2309 VH |
| NCF3010CV | 50 | 80 | 23 | NCF 3010 CV |
| NCF3011CV | 55 | 90 | 26 | NCF 3011 CV |
| NCF2912CV | 60 | 85 | 16 | NCF 2912 CV |
| NCF2913CV | 65 | 90 | 16 | NCF 2913 CV |
| NCF3013CV | 65 | 100 | 26 | NCF 3013 CV |
| NJG2313VH | 65 | 140 | 48 | NJG 2313 VH |
| NCF2914CV | 70 | 100 | 19 | NCF 2914 CV |
| NCF3014CV | 70 | 110 | 30 | NCF 3014 CV |
| NCF2915CV | 75 | 105 | 19 | NCF 2915 CV |
| NCF3015CV | 75 | 115 | 30 | NCF 3015 CV |
| NCF2916CV | 80 | 110 | 19 | NCF 2916 CV |
| NCF3016CV | 80 | 125 | 34 | NCF 3016 CV |
| NCF2917CV | 85 | 120 | 22 | NCF 2917 CV |
| NCF3017CV | 85 | 130 | 34 | NCF 3017 CV |
| NCF2918CV | 90 | 125 | 22 | NCF 2918 CV |
| NCF3018CV | 90 | 140 | 37 | NCF 3018 CV |
| NCF2920CV | 100 | 140 | 24 | NCF 2920 CV |
| NJG2320VH | 100 | 215 | 73 | NJG 2320 VH |
| NCF2922CV | 110 | 150 | 24 | NCF 2922 CV |
| NCF3022CV | 110 | 170 | 45 | NCF 3022 CV |
| NCF2924CV | 120 | 165 | 27 | NCF 2924 CV |
| NCF3024CV | 120 | 180 | 46 | NCF 3024 CV |
| NCF2224V | 120 | 215 | 58 | NCF 2224 V |
| NCF2926CV | 130 | 180 | 30 | NCF 2926 CV |
| NCF3026CV | 130 | 200 | 52 | NCF 3026 CV |
| NCF2928CV | 140 | 190 | 30 | NCF 2928 CV |
| NCF3028CV | 140 | 210 | 53 | NCF 3028 CV |
| NCF2930CV | 150 | 210 | 36 | NCF 2930 CV |
1 . Q : What is your MOQ ?
A : We don't have MOQ, any quanity is ok.
2 . Q : Are you a manufacturer or a trading company ?
A : We are a manufacturer with a professional trading team for 10 years.
3 . Q : How soon could you arrange delivery?
A : It depends on the quantity you ordered . According to common practice, we will arrange delivery within 5 days.
4 . Q : Can I get a sample first ?
A : Yes , Sample is accepted for quality checking.
5 . Q : How to pay for the order ?
A : Western Union, T/T is available ; 30% Deposit and 70% Balance payment at sight of copy of B/L.
6 . Q : Can I do customized logo and package ?
A : Sure , We can print your logo on the bearing , and pack goods based on your requests.
More information and more requests, pls send an inquiry freely.
