Product Details:
|
| Part Number: | 3490/3420 3387/3325 28150/28315A 26878/26824 27800/27820 | Product: | TIMKEN Tapered Roller Bearing |
|---|---|---|---|
| HS Code: | 8482200000 | Lubrication: | Oil Grease |
| Technics: | Salt Bath Quenching | Cage: | Steel , Copper , Nylon |
| Application: | Machine Parts | Surface Treatment: | Nitridation / Rabbet |
| Sample: | Free | OEM: | Accept |
| High Light: | TIMKEN Inch Tapered Roller Bearings,3490/3420 Inch Tapered Roller Bearings |
||
Tapered roller bearings consist of four basic components including: the cone (inner ring), the cup (outer ring), tapered rollers, and a cage (roller retainer). The cone, cup and rollers carry the load while the cage spaces and retains the rollers on the cone. The cone, rollers and cage components of our tapered roller bearings are referred to as the cone assembly. Individual cup and cone components of our tapered roller bearings are available as well as the complete assembly.
Metric Types : 30 series , 31 series , 32 series , 33 series
| Model | D(mm) | d(mm) | B(mm) |
| JH211749 JH211710 | 120 | 65 | 38.5 |
| JH211749A JH211710 | 120 | 65 | 38.5 |
| 6379 6320 | 135.755 | 65.088 | 56.007 |
| H715340 H715311 | 136.525 | 65.088 | 46.038 |
| 5595R 5535 | 122.238 | 65.883 | 43.764 |
| 395A 394A | 110 | 66.675 | 21.996 |
| 395S 394A | 110 | 66.675 | 21.996 |
| 3984 3925 | 112.712 | 66.675 | 30.048 |
| 39590 39520 | 112.712 | 66.675 | 30.162 |
| 39590 39521 | 112.712 | 66.675 | 30.162 |
| 33262 33462 | 117.475 | 66.675 | 30.162 |
| HM212049 HM212010 | 122.238 | 66.675 | 38.354 |
| HM813844 HM813811 | 127 | 66.675 | 36.512 |
| 641 633 | 130.175 | 66.675 | 41.275 |
| 6386 6320 | 135.755 | 66.675 | 56.007 |
| 6389 6320 | 135.755 | 66.675 | 56.007 |
| H414242 H414210 | 136.525 | 66.675 | 41.275 |
| H715341 H715311 | 136.525 | 66.675 | 46.038 |
| 399A 394A | 110 | 68.262 | 21.996 |
| 399AS 394A | 110 | 68.262 | 21.996 |
| 33269 33462 | 117.475 | 68.262 | 30.162 |
| 570 563 | 127 | 68.262 | 36.17 |
| H414245 H414210 | 136.525 | 68.262 | 41.275 |
| H715343 H715311 | 136.525 | 68.262 | 46.038 |
| 9185 9121 | 152.4 | 68.262 | 46.038 |
| LL713049 LL713010 | 98.425 | 69.85 | 13.495 |
| LM613449 LM613410 | 112.712 | 69.85 | 21.996 |
| 29675 29620 | 112.712 | 69.85 | 25.4 |
| 33275 33462 | 117.475 | 69.85 | 30.162 |
| 482 472A | 120 | 69.85 | 29.007 |
| 482 472 | 120 | 69.85 | 29.007 |
| 47487R 47420 | 120 | 69.85 | 32.545 |
| 47487R 47423 | 120.65 | 69.85 | 32.545 |
| 482 472X | 123.825 | 69.85 | 29.007 |
| 566 563 | 127 | 69.85 | 36.17 |
| 655 653 | 146.05 | 69.85 | 41.275 |
| 745AR 742 | 150.089 | 69.85 | 46.672 |
| 835R 832 | 168.275 | 69.85 | 56.363 |
| 34274 34478 | 121.442 | 69.952 | 23.012 |
| JLM813049 JLM813010 | 110 | 70 | 25 |
| JM612949 JM612910 | 115 | 70 | 29 |
| 33281 33462 | 117.475 | 71.438 | 30.162 |
| 47490R 47420 | 120 | 71.438 | 32.545 |
| 567A 563 | 127 | 71.438 | 36.17 |
| HM813849 HM813811 | 127 | 71.438 | 36.512 |
| H414249 H414210 | 136.525 | 71.438 | 41.275 |
| H715345 H715311 | 136.525 | 71.438 | 46.038 |
| 29685 29620 | 112.712 | 73.025 | 25.4 |
| 33287 33462 | 117.475 | 73.025 | 30.162 |
| 567 563 | 127 | 73.025 | 36.17 |
| 576R 572 | 139.992 | 73.025 | 36.098 |
| 657 653 | 146.05 | 73.025 | 41.275 |
| 6460 6420 | 149.225 | 73.025 | 54.229 |
| 744R 742 | 150.089 | 73.025 | 46.672 |
| 762 752 | 161.925 | 73.025 | 48.26 |
| 29688 29620 | 112.712 | 73.817 | 25.4 |
| 568 563 | 127 | 73.817 | 36.17 |
| 577R 572 | 139.992 | 74.612 | 36.098 |
| JLM714149 JLM714110 | 115 | 75 | 25 |
| JM714249 JM714210 | 120 | 75 | 29.5 |
| JH415647 JH415610 | 145 | 75 | 51 |
| 34301 34478 | 121.442 | 76.2 | 23.012 |
| 42687 42620 | 127 | 76.2 | 31 |
| 42688 42620 | 127 | 76.2 | 31 |
| 495AX 492A | 133.35 | 76.2 | 29.769 |
| 47678R 47620 | 133.35 | 76.2 | 33.338 |
| 47680R 47620 | 133.35 | 76.2 | 33.338 |
| 5760 5735 | 135.733 | 76.2 | 46.101 |
| 495A 493 | 136.525 | 76.2 | 29.769 |
| 575R 572 | 139.992 | 76.2 | 36.098 |
| 575SR 572 | 139.992 | 76.2 | 36.098 |
| 6461 6420 | 149.225 | 76.2 | 54.229 |
| 6461A 6420 | 149.225 | 76.2 | 54.229 |
| 748SR 742 | 150.089 | 76.2 | 46.672 |
| 659 652 | 152.4 | 76.2 | 41.275 |
| HH221430 HH221410 | 190.5 | 76.2 | 57.531 |
