1. Cylindrical roller bearings Description :

Cylindrical roller bearings are available in many desigins,series and sizes.The majority are single row bearings with a cage.High-capacity bearings,single and double row full complement bearings complete the standard assortment listed in this catalogue.
Bearings with a cage can accommodate heavy radial loads,rapid accelerations and high speeds.

Full complement bearings incorporate a maximum number of rollers and are therefore suitable for very heavy radial loads at moderate speeds. High-capacity cylindrical roller bearings combine the high load carrying capacity of a full complement bearing with the high speed capability of a bearing with a cage.

2. Types of Cylindrical roller bearings :

N Series- Bearings of N design are single row cylindrical roller bearing and have two fixed ribs on the inner ring that retain the rollers and cage and one smooth outer ring. This design allows an axial displacement in certain limits, of the shaft in relation to the housing. Therefore, N Series rolling bearings are used in non-locating bearing units. Also, the N Series bearings have virtually no thrust capacity.

NU Series- Are single row cylindrical roller bearings and have two fixed ribs on the outer ring and one smooth inner ring. This design allows an axial displacement in certain limits, of the shaft in relation to the housing. Therefore, NU Series rolling bearings are used in non-locating bearing units. Also, the NU Series bearings have no virtually thrust capacity.

NN Series- Bearings of NN design are double row cylindrical roller bearing and have three fixed ribs on the inner ring that retain the rollers and cage and one smooth outer ring. This design allows an axial displacement in certain limits, of the shaft in relation to the housing. Therefore, N Series rolling bearings are used in non-locating bearing units. Also, the NN Series bearings have no virtually thrust capacity.

NNU Series- Are double row cylindrical roller bearings and have three fixed ribs on the outer ring and one smooth inner ring. This design allows an axial displacement in certain limits, of the shaft in relation to the housing. Therefore, NU Series rolling bearings are used in non-locating bearing units. Also, the NNU Series bearings have no virtually thrust capacity.

single row cylindrical roller bearings : N NU NJ NF NUP NFP NH(NJ+HJ)

double row cylindrical roller bearings : NN NNU NNF

four row cylindrical roller bearings : FC FCD

full complement cylindrical roller bearings

3. Model list of Cylindrical Roller Bearing :

4. Application of Roller Bearing :

widely used in automobile, electrical equipment, instrument, building machinery, rolling stock agricultural machinery and various specialized machineries,machine spindle application and are used for cool and hot mills.

5. Package and shipping for Roller Bearing :
