Product Details:
|
| Model: | 6310ZZ 2RSC3 6311 6312 | Precision Rate: | P0,P6,P5,P4,P2 |
|---|---|---|---|
| Structure: | Deep Groove Ball | Seals: | 2RS(Rubber Seals), ZZ(Iron Seals) |
| Material: | Chrome Steel, Stainless Stee | Cage: | Steel Cage Brass Cage |
| Surface Treatmen: | Nitridation / Rabbet | Technics: | Salt Bath Quenching |
| Highlight: | 6311 High Precision Ball Bearing,6312 High Precision Ball Bearing,6310ZZ Bearing |
||
1. Description of Deep groove ball bearing
2. 6300 Seires Model List of Deep groove ball bearing
| Number | Specification | Rated Load(KN) | Speed(r/min) | Weight | ||||
| D(mm) | D(mm) | W(mm) | Cr(N) | Cor(N) | Grease | Oil | kg | |
| 6300 | 10 | 35 | 11 | 6.448 | 2.72 | 16000 | 20800 | 0.053 |
| 6301 | 12 | 37 | 12 | 7.8 | 3.32 | 15200 | 19200 | 0.06 |
| 6302 | 15 | 42 | 13 | 9.12 | 4.32 | 13600 | 16000 | 0.082 |
| 6303 | 17 | 47 | 14 | 10.8 | 5.24 | 12800 | 15200 | 0.12 |
| 6304 | 20 | 52 | 15 | 12.72 | 6.24 | 10400 | 12800 | 0.14 |
| 6305 | 25 | 62 | 17 | 18 | 9.28 | 8800 | 11200 | 0.23 |
| 6306 | 30 | 72 | 19 | 22.48 | 12.8 | 7200 | 8800 | 0.35 |
| 6307 | 35 | 80 | 21 | 26.56 | 15.2 | 6800 | 8000 | 0.46 |
| 6308 | 40 | 90 | 23 | 32.8 | 19.2 | 6000 | 7200 | 0.63 |
| 6309 | 45 | 100 | 25 | 42.16 | 25.2 | 53600 | 6400 | 0.83 |
| 6310 | 50 | 110 | 27 | 49.44 | 30.4 | 5040 | 6000 | 1.05 |
| 6311 | 55 | 120 | 29 | 57.2 | 36 | 4480 | 5360 | 1.35 |
| 6312 | 60 | 130 | 31 | 65.52 | 41.6 | 4000 | 4800 | 1.7 |
Ball bearing Structure :
3. Application of deep groove ball bearing
Here are examples of applications in which deep groove ball bearings might be used :
