Product Details:
|
| Part Number: | LM11949 - 20024 | Product: | Tapered Roller Bearing |
|---|---|---|---|
| Size: | Z1V1 Z2V2 Z3V3 | Material: | 100% Chorme Steel |
| Weight: | 0.244 Kgs | Cage: | Steel |
| Seal Type: | Open | Number Of Row: | Single Row |
| High Light: | Z1V1 TIMKEN Roller Bearing,Z3V3 TIMKEN Roller Bearing |
||
Tapered roller bearings have tapered inner and outer ring raceways, The tapered roller is in the middle of the two raceways. This kind of bearings is usually separatable, namely the retainer, inner ring and outer ring can be installed apart. They can withstand immense radial direction load and certain axial load. They are designed in different sizes and styles to meet all kinds of functions.
Taper roller bearing the angle between the outer raceway generatrix and line, the bearing can bearing heavy load and other Tappered Roller Bearings, it mainly bears joint load based on one way axial load,but not only radial load.
|
Specification
|
Boundary dimensions(mm)
|
Mass(kg)
|
||
|
d
|
D
|
B
|
||
|
LM300849/LM300811
|
41.000
|
68.000
|
17.500
|
0.2420
|
|
33275/33462
|
69.850
|
117.475
|
30.162
|
1.2720
|
|
33281/33462
|
71.438
|
117.475
|
30.162
|
1.2310
|
|
33 8 89/33821
|
50.800
|
95.250
|
27.783
|
0.8680
|
|
33287/33462
|
73.025
|
117.475
|
30.162
|
1.1880
|
|
368A/362A
|
50.800
|
88.900
|
20.638
|
0.5040
|
|
368/362
|
50.800
|
90.000
|
20.000
|
0.5620
|
|
3780/3720
|
50.800
|
93.254
|
30.162
|
0.8560
|
|
3782/3720
|
44.450
|
93.264
|
30.162
|
0.9700
|
|
387A/382A
|
57.150
|
96.838
|
21.000
|
0.5990
|
|
39585/39520
|
63.500
|
112.712
|
30.162
|
1.2580
|
|
2580/2523
|
31.750
|
69.850
|
23.812
|
0.4510
|
|
28985/28921
|
60.325
|
100.00
|
25.400
|
0.7700
|
|
47686/47620
|
82.550
|
133.350
|
33.338
|
1.7570
|
|
47687/47620
|
82.550
|
133.350
|
33.338
|
1.7370
|
|
387A/362S
|
57.150
|
96.838
|
25.400
|
0.6690
|
|
387A/382
|
57.150
|
98.425
|
21.000
|
0.6460
|
|
3982/3920
|
63.500
|
112.712
|
30.162
|
1.2430
|
|
3984/3920
|
66.675
|
112.712
|
30.162
|
1.1660
|
|
462/453X
|
57.150
|
104.775
|
30.162
|
1.0700
|
|
L44643/L44610
|
25.400
|
50.292
|
14.224
|
0.1290
|
|
L4469/L44610
|
26.988
|
50.292
|
14.224
|
0.1200
|
|
L45449/L45410
|
29.000
|
50.292
|
14.224
|
0.1150
|
|
LM48548/LM48510
|
34.925
|
65.088
|
18.034
|
0.2590
|
|
LM501349/LM501210
|
41.275
|
73.431
|
19.558
|
0.3340
|
|
LM501349/LM501314
|
41.275
|
73.431
|
21.430
|
0.3550
|
