Double Row TIMKEN Tapered Roller Bearings 42381/42597D GCr15 Chrome Steel

Double Row TIMKEN Tapered Roller Bearing 42381 / 42597D 96.838*149.225*28.971mm TIMKEN BEARINGS weight 3.68 Kgs

TIMKEN 42381/42597D is an Inch Double row Taper Roller Bearing with Inside Diameter: 96.838mm Outside Diameter: 149.225mm Thickness: 28.971mm Weight:3.68KG

WUXI HANDA Bearing Co.,LTD is specialized in supplying TIMKEN 42381/42597D with stocks for years,welcome to contact us for details about this Inch type Double row Tapered Roller Bearing.

Timken offers the most extensive line of tapered roller bearings in the world. Tapered roller bearings consist of four interdependent components: the cone (inner ring), the cup (outer ring), the tapered rollers (rolling elements) and the cage (roller retainer). Tapered roller bearings are uniquely designed to manage both thrust and radial loads between a rotating and non-rotating member. The steeper the cup angle, the greater the ability of the bearing to handle thrust loads.

Double Row Tapered Roller Bearing types and cages :

This has a one-piece (double) outer ring and two single inner rings. It is usually supplied complete with an inner-ring spacer as a pre-set assembly. This configuration gives a wide effective bearing spread and is frequently chosen for applications where overturning moments are a significant load component. TDO bearings can be used in fixed (locating) positions or allowed to float in the housing bore, for example, to compensate for shaft expansion. TDOCD outer rings also are available in most sizes. These outer rings have holes in the O.D. that permit the use of pins to prevent outer ring rotation in the housing.

TDO (Two-Row Double-Outer Race)

The configuration of the TDO provides a wide effective bearing spread, making it ideal for applications in which overturning moments are a significant load component. TDO bearings can be used in fixed positions or allowed to float in the housing bore.

Size range:

ID 25.400 mm to 1200.150 mm (1.0000 in. to 47.2500 in.)
OD 30.480 mm to 2460.000 mm (1.2000 in. to 96.8504 in.)

Design Attributes:

Double cup and two single cones, with or without a spacer.
When spacers are used, bearing is furnished as a preset, matched assembly.
Cup features groove and lubrication holes in the OD.
Spacers available with or without lubricant grooves and holes.

Applications:

Heavy-duty gear drives
Various industrial configurations

How to buy TIMKEN 42381/42597D from us?

Or need some other TIMKEN Tapered Roller Bearing ?

Just leave a comment or contact us by email.

We will reply you asap.
