UCPA210 Plummer Block Housing Bearing PA210 Pillow Type Unit Cylindrical Bore Type

Large Image : UCPA210 Plummer Block Housing Bearing PA210 Pillow Type Unit Cylindrical Bore Type

Product Details:

Place of Origin:	CHINA JAPAN
Brand Name:	HDBB NACHI
Certification:	ISO9001 & GB307
Model Number:	UCPA210

Payment & Shipping Terms:

Minimum Order Quantity:	10 Pcs
Packaging Details:	Industrial Packing Single Color Box OEM
Delivery Time:	5-7 Works days
Payment Terms:	T/T , Western Union, RMB
Supply Ability:	80,000 Pcs per Month

Contact Now

UCPA210 Plummer Block Housing Bearing PA210 Pillow Type Unit Cylindrical Bore Type

Description

Part Number:	UCPA210	Housing Type:	Pillow Block Unit
Bearing Type:	Insert Ball Bearings	Bearing:	UC210
Housing:	PA210 Y	Housing Material:	Cast Iron
Unit Weight:	2.25 Kgs	Fastening Bolt Hole Typeing:	Threaded
High Light:	UCPA210 Plummer Block Housing Bearing , PA210 Plummer Block Housing Bearing

UCPA210 Plummer Block Housing Bearing PA210 NACHI Pillow-Type Unit, Cylindrical Bore Type With Set Screws UCPA Type

Short base pillow block ball bearing unit with extended inner ring and set screw locking, Japanese Industrial Standards.

Pillow (plummer) block ball bearing units consist of an insert bearing mounted in a cast iron housing. This variant has threaded holes for attachment bolts and is suitable for applications where the direction of rotation is constant or alternating. It has an inner ring extended on both sides and is locked onto the shaft by tightening two set screws on the inner ring, making it easy to mount. The units are compliant with Japanese Industrial Standards (JIS).

UCPA plummer block housing units size:

Bearing NO.	Shaft Dia.		Dimensions(mm)				Bearing No.	Housing No.	KGS
	d		H	L	J	M
	(in.)	(mm)	H	L	J	M
UCPA202		15	30.2	76	52	M10×1.5	UC202	PA204	0.63
UCPA202-10	5/8		30.2	76	52	M10×1.5	UC202-10	PA204	0.63
UCPA203		17	30.2	76	52	M10×1.5	UC203	PA204	0.63
UCPA203-11	11/16		30.2	76	52	M10×1.5	UC203-11	PA204	0.63
UCPA204-12	3/4		30.2	76	52	M10×1.5	UC204-12	PA204	0.63
UCPA204		20	30.2	76	52	M10×1.5	UC204	PA204	0.63
UCPA205-14	7/8		36.5	84	56	M10×1.5	UC205-14	PA205	0.8
UCPA205-15	15/16		36.5	84	56	M10×1.5	UC205-15	PA205	0.8
UCPA205		25	36.5	84	56	M10×1.5	UC205	PA205	0.8
UCPA205-16	1		36.5	84	56	M10×1.5	UC205-16	PA205	0.8
UCPA206-18	1-1/8		42.9	94	66	M14×2	UC206-18	PA206	1.2
UCPA206		30	42.9	94	66	M14×2	UC206	PA206	1.2
UCPA206-19	1-3/16		42.9	94	66	M14×2	UC206-19	PA206	1.2
UCPA206-12	1-1/4		42.9	94	66	M14×2	UC206-20	PA206	1.2
UCPA207-20	1-1/4		47.6	110	80	M14×2	UC207-20	PA207	1.7
UCPA207-21	1-5/16		47.6	110	80	M14×2	UC207-21	PA207	1.7
UCPA207-21	1-5/16		47.6	110	80	M14×2	UC207-21	PA207	1.7
UCPA207-22	1-3/8		47.6	110	80	M14×2	UC207-22	PA207	1.7
UCPA207		35	47.6	110	80	M14×2	UC207	PA207	1.7
UCPA207		35	47.6	110	80	M14×2	UC207	PA207	1.7
UCPA207-23	1-7/16		47.6	110	80	M14×2	UC207-23	PA207	1.7
UCPA208-24	1-1/12		49.2	116	84	M14×2	UC208-24	PA208	2.0
UCPA208-25	1-9/16		49.2	116	84	M14×2	UC209-25	PA208	2.0
UCPA208		40	49.2	116	84	M14×2	UC208	PA208	2.0
UCPA209-26	1-5/8		54.2	120	90	M14×2	UC209-26	PA209	2.2
UCPA209-26	1-5/8		54.2	120	90	M14×2	UC209-26	PA209	2.2
UCPA209-27	1-11/16		54.2	120	90	M14×2	UC209-27	PA209	2.2
UCPA209-28	1-3/4		54.2	120	90	M14×2	UC209-28	PA209	2.2
UCPA209		45	54.2	120	90	M14×2	UC209	PA209	2.2
UCPA210-30	1-7/8		57.2	130	94	M16×2	UC210-30	PA210	2.8
UCPA210-31	1-15/16		57.2	130	94	M16×2	UC210-31	PA210	2.8
UCPA210		50	57.2	130	94	M16×2	UC210	PA210	2.8
UCPA210-32	2		57.2	130	94	M16×2	UC210-32	PA211	2.8
UCPA211-32	2		63.5	140	104	M16×2	UC211-32	PA211	3.0
UCPA211-34	2-1/8		63.5	140	104	M16×2	UC211-34	PA211	3.0
UCPA211		55	63.5	140	104	M16×2	UC211	PA211	3.0
UCPA211-35	2-3/16		63.5	140	104	M16×2	UC211-35	PA211	3.0
UCPA211-35	2-3/16		63.5	140	104	M16×2	UC211-35	PA211	3.0
UCPA212-36	2-1/4		69.9	150	114	M16×2	UC212-36	PA212	4.24
UCPA212		60	69.9	150	114	M16×2	UC212	PA212	4.24
UCPA212-38	2-3/8		69.9	150	114	M16×2	UC212-38	PA212	4.24
UCPA212-39	2-7/16		69.9	150	114	M16×2	UC212-39	PA212	4.24
UCPA213-40	2-1/2		76.2	160	124	M16×2	UC213-40	PA213
UCPA213-213		65	76.2	160	124	M16×2	UC213	PA213
UCPA201S		12	30.2	70	48	M8×1.25	UC201S	PA203
UCPA201-8S	1/2		30.2	70	48	M8×1.25	UC201-8S	PA203
UCPA202S	5/8		30.2	70	48	M8×1.25	UC202S	PA203
UCPA203S		17	30.2	70	48	M8×1.25	UC202-10S	PA203
UCPA203-11S		11/16	30.2	70	48	M8×1.25	UC203-11S	PA203
UCPA201		12	30.2	76	52	M10×1.5	UC201	PA204	0.63

Bearing Unit Types :

UCP... 200 300 Series

UCT... 200 300 Series

UCF... 200 300 Series

UCPA ... 200 300 Series

UCFL ... 200 300 Series

UCFC ... 200 300 Series

UCPA210 Plummer Block Housing Bearing PA210 Pillow Type Unit Cylindrical Bore Type 0

UCPA210 Plummer Block Housing Bearing PA210 Pillow Type Unit Cylindrical Bore Type 1

UCPA210 Plummer Block Housing Bearing PA210 Pillow Type Unit Cylindrical Bore Type 2

For more PILLOW BLOCK BEARINGS size, pls contact us freely.
