Product Details:
|
| Model: | NAV 4007 NAV4009 | Type: | Needle Roller Bearing |
|---|---|---|---|
| Size: | 35X62X27mm 45X75X30mm | Application: | Engineering Machinery |
| Material: | Bearing Steel | HS Code: | 8482400000 |
| Highlight: | NAV 4007 Needle Roller Bearing,Full Complement Needle Roller Bearing,NAV4009 Full Complement Needle Bearing |
||
How are needle roller bearings measured ?
Measuring your bearing: Most bearings are measured in three ways, the inside diameter or (ID), the outside diameter or (OD) and the width or (W). It is important to note that our bearing measurements are all done in the following order: Inside diameter (ID) x Outside diameter (OD) x Width (W).
Are needle roller bearings self aligning ?
Alignment needle roller bearings are self-aligning up to 3° of static misalignment. In applications where less space is available, alignment needle roller bearings offer a compact solution. Owing to their large number of rollers, alignment needle roller bearings have a high load carrying capacity.
| Model | d(mm) | D(mm) | B(mm) |
| NAV4003 | 17 | 35 | 18 |
| NAV4004 | 20 | 42 | 22 |
| NAV4005 | 25 | 47 | 22 |
| NAV4006 | 30 | 55 | 25 |
| NAV4007 | 35 | 62 | 27 |
| NAV4008 | 40 | 68 | 28 |
| NAV4009 | 45 | 75 | 30 |
| NAV4010 | 50 | 80 | 30 |
| NAV4011 | 55 | 90 | 35 |
| NAV4012 | 60 | 95 | 35 |
| NAV4013 | 65 | 100 | 35 |
| NAV4014 | 70 | 110 | 40 |
| NAV4015 | 75 | 115 | 45 |
| NAV4016 | 80 | 125 | 45 |
| NAV4017 | 85 | 130 | 45 |
| NAV4903 | 17 | 30 | 13 |
| NAV4904 | 20 | 374 | 17 |
| NAV4905 | 25 | 42 | 17 |
| NAV4906 | 30 | 47 | 17 |
| NAV4907 | 35 | 55 | 20 |
| NAV4908 | 40 | 62 | 22 |
| NAV4909 | 45 | 68 | 22 |
| NAV4910 | 50 | 72 | 22 |
| NAV4912 | 60 | 85 | 25 |
| NAV4914 | 70 | 100 | 30 |
| NAV4916 | 80 | 110 | 30 |
| NAV4918 | 90 | 125 | 35 |
| NAV4919 | 95 | 130 | 35 |
| NAV4920 | 100 | 140 | 40 |
| NAV4922 | 110 | 150 | 40 |
| NAV4924 | 120 | 165 | 45 |
| NAV4926 | 130 | 180 | 50 |
| NAV4928 | 140 | 190 | 50 |
| NAV4930 | 150 | 210 | 60 |
| Package | Plastic Tube for bearings, and carton package outside | ||||||
| Shipping | Express,air shipment, and sea shipment are available | ||||||
| Service | OEM Service, and can print your own logo after authorization | ||||||
