Product Details:
|
| Model: | 7008CTYNSULP4 | Structure: | Angular Contact |
|---|---|---|---|
| Size: | 40X68X15mm | Weight: | 0.21 Kg |
| Precision: | P4 | No. Of Row: | Single Row |
| Material: | GCR15 | HS Code: | 8482103000 |
| Lubrification: | Grease Lubricated | ||
| Highlight: | High Precision NSK Spindle Bearings,7008CTYNSULP4,7008 Angular Contact Ball Bearing |
||
What are super precision bearings ?
These bearings are typically used to support rotating tables, indexing tables and milling heads. Their internal design, together with their high degree of running accuracy, enables very precise positioning of the workpiece or the working head.
Are NSK bearings any good ?
NSK is a global bearing company with over 100 years of history. It offers the highest levels of safety and Japanese quality. Genuine NSK bearings are much more cost effective than fake bearings because they last much longer and you don't have to pay for repairs caused by failures.
| Model No. | Size(d*D*B) mm | Weight (KG) | Model No. | Size(d*D*B) mm | Weight (KG) |
| 724C | 4*13*5 | 0.005 | 7224C | 120*215*40 | 5.6 |
| 725C | 5*16*5 | 0.008 | 7226C | 130*230*40 | 7.3 |
| 726C | 6*19*6 | 0.01 | 7228C | 140*250*42 | 8.6 |
| 727C | 7*22*7 | 0.013 | 7230C | 150*270*45 | 12.1 |
| 728C | 8*24*8 | 0.017 | 7232C | 160*290*48 | 14.5 |
| 729C | 9*26*8 | 0.02 | 7234AC | 170*310*52 | 17.2 |
| 7200C | 10*30*9 | 0.031 | 7236AC | 180*320*52 | 17.9 |
| 7201C | 12*32*10 | 0.036 | 7238AC | 190*340*55 | 20 |
| 7202C | 15*35*11 | 0.04 | 7240AC | 200*360*58 | 25.2 |
| 7203C | 17*40*12 | 0.063 | 7244AC | 220*400*65 | 36.1 |
| 7204C | 20*47*14 | 0.102 | 7248B | 240*440*72 | 50.9 |
| 7205C | 25*52*15 | 0.127 | 7303C | 17*47*14 | 0.12 |
| 7206C | 30*62*16 | 0.233 | 7304C | 20*52*15 | 0.15 |
| 7207C | 35*72*17 | 0.3 | 7305C | 25*62*17 | 0.23 |
| 7208C | 40*80*18 | 0.37 | 7306C | 30*72*19 | 0.35 |
| 7209C | 45*85*19 | 0.5 | 7307C | 35*80*21 | 0.47 |
| 7210C | 50*90*20 | 0.46 | 7308C | 40*90*23 | 0.66 |
| 7211C | 55*100*21 | 0.6 | 7309C | 45*100*25 | 0.888 |
| 7212C | 60*110*22 | 0.8 | 7310C | 50*110*27 | 1.08 |
| 7213C | 65*120*23 | 1.02 | 7311C | 55*120*29 | 1.44 |
| 7214C | 70*125*24 | 1.1 | 7312C | 60*130*31 | 1.71 |
| 7215C | 75*130*25 | 1.29 | 7313C | 65*140*33 | 2.23 |
| 7216C | 80*140*26 | 1.48 | 7314C | 70*150*35 | 2.67 |
| 7217C | 85*150*28 | 1.84 | 7315C | 75*160*37 | 3.1 |
| 7218C | 90*160*30 | 2.24 | 7316C | 80*170*39 | 3.97 |
| 7219C | 95*170*32 | 3.2 | 7317C | 85*180*41 | 4.84 |
| 7220C | 100*180*34 | 3.27 | 7318C | 90*190*43 | 5 |
| 7221C | 105*190*36 | 3.95 | 7319C | 95*200*45 | 5.7 |
| 7222C | 110*200*38 | 4.81 | 7320C | 100*215*47 | 8.5 |
Delivery Ways for NSK Ball Bearings :
