Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3

Large Image : Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3

Product Details:

Place of Origin:	GERMANY
Brand Name:	FAG
Certification:	ISO9001
Model Number:	241/560-BEA-XL-K30-MB1-C3

Payment & Shipping Terms:

Minimum Order Quantity:	10 Pcs
Packaging Details:	Single Color Box Standard Packing
Delivery Time:	5-7 Works days
Payment Terms:	T/T , Western Union, RMB
Supply Ability:	80,000 Pcs per Month

Contact Now

Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3

Description

Bearing No.:	241/560-BEA-XL-K30-MB1-C3	Type:	Spherical Roller Bearing
Size:	560X920X355mm	Weight:	903Kgs
Row Number:	Double Row	Bore:	C - Cylindrical Bore
Lubrication Enhancement:	W33 - Lubrication Groove And 3 Holes	Cage:	CC CCK CA CAK E MB
Highlight:	Heavy Duty FAG Tapered Roller Bearing , Spherical FAG Tapered Roller Bearing , FAG Mining Bearings

FAG 241/560-BEA-XL-K30-MB1-C3 Spherical Roller Bearing 560X920X355mm Weight 903Kgs Mining Bearings Heavy Duty

Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3 0

Cylindrical bore & Tapered bore

Spherical roller bearings Part of Models:

Bearings NO.(K)	d/mm	D/mm	B/mm	Weight/kg
24120	100	165	65	5.65
24122	110	180	69	6.9
24124	120	200	62	7.63
24126	130	210	80	11.7
24128	140	225	85	13.2
24130	150	250	100	20.4
24132	160	270	109	25.4
24134	170	280	109	27.9
24136	180	300	118	34.7
24138	190	320	128	42.9
24140	200	340	140	50.5
24144	220	370	150	68.8
24148	240	400	160	81.6
24152	260	440	180	112
24156	280	460	180	122
24160	300	500	200	159
24164	320	540	218	247
24168	340	580	243	267
24172	360	600	243	280
24176	380	620	243	288
24180	400	650	250	340
24184	420	700	280	445
24188	460	720	280	460
24192	460	760	300	539
24196	480	790	308	602
239/500	500	670	128	128.5
241/530	530	870	335	792
241/560	560	920	355	903
239/630	630	850	165	272.5
239/670	670	900	170	307.2
239/710	710	950	180	389

The installation axial clearance of the spherical roller bearing can be adjusted by the adjusting nut on the journal, the adjusting washer and the thread in the bearing seat hole, or by the method of preloading the spring. The size of the axial clearance is related to the arrangement of the bearing during installation, the distance between the bearings, and the material of the shaft and the bearing seat, which can be determined according to the working conditions.

Application of Bearing :

1 ) . Cement Industry

Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3 1

2 ) . Metal Industry

Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3 2

3 ) . Thermal power plant

Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3 3

4 ) . Baler Bearings

Mining Spherical FAG Tapered Roller Bearing Heavy Duty 241/560-BEA-XL-K30-MB1-C3 4
